VM8/12 SERIES VERTICAL MULTISTAGE CENTRIFUGAL PUMPS

RANGE OF PERFORMANCE
8Flow rate up to 120 l/min (7.2 m3/h)
8Head up to 55m

LIMITS OF USE
8Manometric suction lift up to 9m
8Liquid temperature up to +70℃
8Environment temperature up to +50℃
8Max.working pressure: 1.0Mpa

INSTALLATION AND USE
8These pumps are suitable for handling clean water
without abrasive particles and liquids that are chemically
non-aggressive to the pump components. Reliable,
economical and simple to use, they are suitable for
domestic use and in particular for distributing water in
combination with small pressure sets, for irrigating gardens.
The pumps must be installed in a covered area, protected
against the inclement weather.

MOTOR
8Two –pole induction motor (n=2850rpm)
8Insulation Class F
8Protection grade IP55

MATERIALS
8Pump body: Cast iron with stainless steel
8Pump  support: Cast iron
8Motor housing: Aluminum
8Impeller: PPO
8Shaft with rotor: AISI420 stainless steel
8Mechanical seal: NBR/Ceramic/ Carbon
8Bearing:  NSK, C&U, or local quality.

WARRANTY: 1 YEAR (according to our general sales conditions)

MODEL
POWER
RATED HEAD
RATED FLOW
DNA
DNM
WEIGHT  PACKING SIZE
1 phase 3 phase
(Kw)
(HP)
(m)
 (m3/h)
(Kg)
(mm)
VM8-9X2 VM8-9X2T 1.1 1.5 18 8 G11/2 G11/4 21 500*220*300
VM8-9X3 VM8-9X3T 1.1 1.5 27 22 540*220*300
VM8-9X4 VM8-9X4T 1.5 2.0 36 23 580*220*300
--- VM8-9X5T 2.2 2.5 45 25 615*220*300
--- VM8-9X6T 3.0 4.0 54 26 95*220*300
VM12-8.5X2 VM12-8.5X2T 1.1 1.5 17 12 22 500*220*300
 VM12-8.5X3 VM12-8.5X3T 1.5 2.0 25 24 540*220*300
--- VM12-8.5X4T 2.2 2.5 34 26 580*220*300
--- VM12-8.5X5T 3.0 4.0 42 27 655*220*300
--- VM12-8.5X6T 3.0 4.0 51 29.5 695*220*300
--- VM12-8.5X7T 4.0 5.5 55 30 770*230*300

8Three-phase 220/380V-50Hz (60hz), single phase 220V/60Hz, 110V/60Hz, 127V/60Hz & 110V/220V/60Hz are available on request.
